Permanent Magnets

Simulation in Permanent magnets is strongest feature of INTEGRATED Engineering Software programs. These are highly accurate and easy to use magnets design software programs, able to handle large and complex simulations routinely. They are used for calculation of magnetic fields caused by combination of local and/or distributed direct currents, permanent magnets and also external fields defined by boundary conditions.

MainMagnets

Following magnetic parameters are calculated with high accuracy:

  • Permanent magnet parameters: magnetic flux density, field intensity, potential, permeability, energy, self and mutual inductances, magnetic forces, torques, and other integral quantities
  • Calculation of static magnetic fields caused by permanent magnets and also external fields defined by boundary conditions.
  • Analyze permanent magnets and time dependent current sources simultaneously

For many low frequency magnetic problems Boundary Element Method (BEM) is a clearly superior solver. Finite Element Method (FEM) solver is also incorporated so that a user can obtain independent verification of a solution simply by switching the solver setting rather than having to create a whole new model in a separate program.
