ELECTRIC Field

Design of high voltage equipment and other devices utilizing electric fields require accurate calculation of electrical stress in order to reduce flashover or meet many other design criteria.

Electric Field
MAGNETIC Field

Design of electro mechanical equipment such as motors and solenoids requires electromagnetic simulation software specifically designed for magnetic analysis which inherently includes coils and windings and the ability to do transient analysis.

Magnetic Field
PARTICLE TRAJECTORY

Applications utilizing electron or ion beams or traps deliberately make use of this motion and require the modeling of beam optics and/or particle trajectories.

Particle Trajectory
MICROWAVE and ANTENNAS

INTEGRATED's simulation tools are developed specifically for engineers and scientists who need to address the challenges od modeling and simulating antennas and RF applications.

Microwave Antennas
SYSTEM SIMULATION

Modern design of electrical energy conversion systems which includes power electronics require the support of simulation tools. A system or circuit simulation alone is no longer satisfactory without proper combined-physics system analysis and design.

System Simulation
THERMAL SYSTEMS

Predicting the temperature rise in conducting bodies is a challenging analysis problem requiring coupled electromagnetic and thermal field solutions.

Thermal Systems
